Data List MX-6 LEDs
MX Binning \u0026 Labeling
Product Photos MX6AWT-A1 Series
Catalog Drawings MX6AWT Series Bottom
MX6AWT Series Side
MX6AWT Series Top
Featured Products ? MX-6 LEDs
Standard Package 1
Category Optoelectronics
Family LED lighting - White
series ? MX-6
package Cut Tape (CT)
CCT (K) 5000K (4500K ~ 5350K)
25 ° C, flux , Current - Test 104 lm (100 lm ~ 107 lm)
Current - Test 300mA
Voltage - Forward (Vf) ( typical) 3.3V
CRI ( color rendering index ) 75
Current - the maximum 1A
Perspective 120 °
Mounting Type Surface Mount
Package / Case 2-SMD, Gull Wing tabs
Lumen different test when the current / watt 105 lm / W
85 ° C when the flux , Current - Test 88 lm
Package Thermal Resistance 5 ° C / W
Catalog Page 2895 (CN2011-ZH PDF)
Equipped with
876-1003-ND - LM3406 LED DRIVER EVAL BOARD
