MC-38A Door Magnetic Burglar Alarm Wired Door and Window Detector Door Magnetic Switch Sensor Normally Open Normally Closed
Description:
Model: MC-38A
Appearance size: 27*14*8 mm
Action distance: 18mm ± 10mm
Switch withstand voltage: 60VDC
Load current: 150mA
Surface mounting type, suitable for surface mounting of non-ferrous doors or windows
Note:
If the door sensor is to be energized, the voltage is controlled at dc0v-24v, and the power supply current cannot exceed 1A. The load current cannot exceed 150ma, and we will not be responsible for burns if it exceeds the standard.
