Pneumatikus 3 pozíció 4 port 1/4BSP HV-02 kézi működtetésű karos levegőszelep
Pneumatic 3 Positions 4 Ports 1/4BSP HV-02 Hand Operated Lever Air Valve
Specification:
Product Name: Hand Lever Valve
Model :HV-02
Fluid :Air
Joint Pipe Size: 1/4BSP
Joint Pipe Dia: 11.8mm
Action Direct Acting Type
Actuation Type
3 Position 4 Way 4 Port
Max. Pressure: 1MPa
Valve Siz: 73 x 73 x 85mm/ 2.9" x 2.9" x 3.4" (L*W*H)
Lever Size: 88 x 9mm/ 3.5" x 0.35" (L*D)
Fixing Hole Diameter :6mm/ 0.24"
Fixing Hole Center Distance 62 x 62mm/2.5" x 2.5"(L*W)
Package Content 1 x Hand Lever Valve
