Nincs szín - Lépcsős tápegység Kompakt, strapabíró, tartós 24 V-tól 12 V 60 A-ig Nem szigetelt
Nincs szín - Lépcsős tápegység Kompakt, strapabíró, tartós 24 V-tól 12 V 60 A-ig Nem szigetelt
3 343 Ft
58,5% megtakarítás
8 056 Ft
Nincs adó
Features:
1. Adopting imported components, conversion efficiency up to 96% , stable output.
2. Wide input voltage, built-in overcurrent, overvoltage, over temperature, short circuit and other automatic protection functions.
3. Sealed with high quality thermal conductive silicone, IP68 waterproof, dustproof, anti-shock.
4. Die-cast aluminum shell, compact size, convenient to install.
5. Quality assurance, service life up to 100,000 hours.
Specification:
Model: WG-24S1260
Input voltage: DC 24V
Input voltage range: DC 18-36V
Conversion efficiency: 96%
Output voltage: 12V
Output current: 60A
Rated output power: 720W
Output peak power: 130%
Voltage regulation ratio: <1%
Load regulation ratio: <2%
No load current: <40mA
Ripple: <300mV
Working temperature: -35~80â„
Waterproof rating: IP68
Item size: 150*127*63mm / 5.9*5*2.5in
Package weight: Approx. 1490g / 52.5oz
Package list:
1 * DC-DC Power Supply
Note:
1. Due to the difference between monitors and light effects, the pictures may not reflect the actual color of the item.
1. Adopting imported components, conversion efficiency up to 96% , stable output.
2. Wide input voltage, built-in overcurrent, overvoltage, over temperature, short circuit and other automatic protection functions.
3. Sealed with high quality thermal conductive silicone, IP68 waterproof, dustproof, anti-shock.
4. Die-cast aluminum shell, compact size, convenient to install.
5. Quality assurance, service life up to 100,000 hours.
Specification:
Model: WG-24S1260
Input voltage: DC 24V
Input voltage range: DC 18-36V
Conversion efficiency: 96%
Output voltage: 12V
Output current: 60A
Rated output power: 720W
Output peak power: 130%
Voltage regulation ratio: <1%
Load regulation ratio: <2%
No load current: <40mA
Ripple: <300mV
Working temperature: -35~80â„
Waterproof rating: IP68
Item size: 150*127*63mm / 5.9*5*2.5in
Package weight: Approx. 1490g / 52.5oz
Package list:
1 * DC-DC Power Supply
Note:
1. Due to the difference between monitors and light effects, the pictures may not reflect the actual color of the item.
