DC 5V 12V Touch Switch Modul 0-130s Delay Timer Button Board for Arduino UNO Relay
DC 5V 12V Touch Switch Module 0-130s Delay Timer Button Board for Arduino UNO Relay

Typical applications:
Arduiuo UNO MEGA2560 Pro mini DUE
ARM MCU FPGA/CPLD Development Board
raspberry pi
5V/12V Relay Module

Product Name:DC 5V 12V Touch Module 0-130s Delay Timer Button Board for Arduiuo UNO Relay raspberry pi
Packing list:

1 pcs  DC 5V 12V Touch Module 0-130s Delay Timer Button Board


Description:

Click the "touch key" with your finger,Then "OUT pin" output high after the delay 0-130 seconds to restore low

Time delay 0-130 seconds adjustable
2.54mm pin
PCB Size : 32MM X 20MM X 13MM


VCC : 5V-12V Power supply positive
GND : Power supply negative
OUT : Trigger Output(4V-11V,VCC-1V)





Connected with the 12V relay module:
